MC Hand with Quick Disconnect Wrist
The Motion Control (MC) Hand sets the standard for rugged functionality. It comes in three sizes and is made with high-strength, CNC machined fingers in either aluminum or stainless steel. It features a wide opening and a built-in manual safety release serving as a useful tool for many tasks and lifestyles. For high durability and high speed, a brushless DC motor is used offering a smoother, quieter and more controlled experience. The MC Hand can be used with the Utah Arm, Motion Arm or ProControl 2 system and is interchangeable with almost every industry system available. The MC Hand comes in Motor Direct (no controller, one must be located up-stream) or ProPlus which features a controller inside the Hand allowing interchange with other manufacturers’ systems. Force Limiting Autograsp (FLAG) for regulated pinch force is also available. Fits most high-quality cosmetic gloves. This item includes the MC Hand with a Quick Disconnect Wrist attached. Configuration options are available.
Suggested L Codes: L6621, L6881, L6882, L6935, L7007
PRODUCTS IN THIS SERIES:
Interested in these products?
The Motion Control Hand.
Powerful and responsive, the MC Hand sets the standard for rugged functionality. Add FLAG for additional force control.
Which Wrist Should I Choose?
Flexion
The Flexion Wrist allows a hand to be moved and locked at 30 degrees flexion and extension for optimal positioning while eating, driving, etc. A manual lever locks the Wrist in position.
Multi-Flex
The Multi-Flex Wrist moves in multiple directions and can be locked in place. The spring loaded centering provides a “natural” feel as the wrist can flex in any direction as needed to adjust to the loads placed on it.
Powered Flexion
The high-speed myo controller in the PFW provides proportional control of flexion/extension, a pause feature, TD/Wrist switching and hands-free targeting. The PFW is IPX7 water resistant.
Myo Wrist Choices.
Choosing the best wrist for the patient.
MC PROPLUS HAND DOCUMENTS
| LANGUAGE | PROSTHETIST | USER | |
|---|---|---|---|
 |
English | Prosthetist Manual | User Guide |
 |
Spanish/Español | Prosthetist Manual | User Guide |
 |
French/Français | Prosthetist Manual | User Guide |
 |
German/Deutsch | Prosthetist Manual | User Guide |
 |
Italian/Italiano | Prosthetist Manual | User Guide |
 |
Swedish/Svenska | Prosthetist Manual | User Guide |
 |
Norwegian/Norsk | Prosthetist Manual | User Guide |
 |
Danish/Dansk | Prosthetist Manual | User Guide |
 |
Dutch/Nederlands | Prosthetist Manual | User Guide |
 |
Finnish/Suomi | Prosthetist Manual | User Guide |
Additional MC Hand Documents
