MYO Motion Arm

Introducing the Motion Arm. Robust, durable and IP67 certified dustproof/waterproof they are built to be used!

The Motion Arm Manual Lock (ML) body powered hybrid elbow for use with electric terminal devices and passive or electric wrist rotators. The lock mechanism will support up to 50ft-lbs. The elbow comes with an adjustable lift tab and spectra lock/unlock cable. Indicator lights show the amount of charge in the battery.

The Motion Arm EL has an electric lock/unlock mechanism perfect for short transhumeral and high-level amputation levels as well as mid to long transhumeral amputation levels. There are 3 lock/unlock triggers and the availability use a switch. To adjust the trigger parameters, the Motion Arm User Interface (MAUI) easily connects your Apple® handheld device to the processer via Bluetooth®.

DOCUMENTS

LANGUAGEPROSTHETISTUSEROTHER
EnglishProsthetist ManualUser GuideCutting Guide
Spanish/EspañolProsthetist ManualUser GuideCutting Guide
French/FrançaisProsthetist ManualUser GuideCutting Guide
German/DeutschProsthetist ManualUser GuideCutting Guide
Italian/ItalianoProsthetist ManualUser GuideCutting Guide
Swedish/SvenskaProsthetist ManualUser GuideCutting Guide
Norwegian/NorskProsthetist ManualUser GuideCutting Guide
Danish/DanskProsthetist ManualUser GuideCutting Guide
Dutch/NederlandsProsthetist ManualUser GuideCutting Guide
Finnish/SuomiProsthetist ManualUser GuideCutting Guide
Polish/PolskiProsthetist ManualUser GuideCutting Guide
